In electronic experiments, equipment debugging, and industrial power supply scenarios, adjustable power supplies are core devices for achieving flexible voltage control and stable output. The voltage regulation process of their circuits is crucial to ensuring that the output voltage is unaffected by input voltage fluctuations and load changes. Voltage regulation in an adjustable power supply is not simply the function of a single component, but a closed-loop control process completed collaboratively by four core circuits: sampling, comparison, adjustment, and reference. Under different operating conditions, each circuit module works together to ensure that the adjustable power supply always outputs a stable preset voltage. YIBENYUAN's adjustable power supplies, thanks to their optimized voltage regulation circuit design, maintain excellent output stability in various voltage regulation power supply scenarios.
The reference voltage circuit provides a precise reference standard
The reference voltage circuit is the foundation of the adjustable power supply's voltage regulation operation, providing a stable and accurate voltage reference value for the entire voltage regulation system. This is an important basis for subsequent voltage comparison and adjustment. This circuit often uses high-precision Zener diodes or dedicated reference voltage chips, ensuring that it always outputs a fixed reference voltage even with small fluctuations in input voltage and changes in ambient temperature, without numerical deviation due to external factors. The voltage regulation accuracy of an adjustable power supply primarily depends on the output stability of the reference voltage circuit. Only with a precise reference standard can subsequent voltage regulation be accurate.
Sampling Circuit: Real-time Acquisition of Output Voltage Signal
The output of the adjustable power supply is connected to a sampling circuit. Its core function is to acquire the actual output voltage value in real time, reduce this voltage signal by a certain ratio, and then transmit it to the comparator amplifier circuit. The sampling circuit typically consists of a voltage divider network composed of precision resistors. When the user adjusts the output voltage of the adjustable power supply, they are actually changing the resistor ratio of the voltage divider network, causing the voltage signal acquired by the sampling circuit to change accordingly, thus matching different preset output voltages. Simultaneously, the sampling circuit can sensitively capture subtle fluctuations in the output voltage, even if the load current changes, it can quickly transmit the voltage change signal for real-time monitoring.
Comparator Amplifier Circuit: Comparison and Amplification of Signal
The comparison and amplification circuit is the "core brain" of the voltage stabilization regulation of the adjustable power supply. One end receives the actual voltage signal transmitted by the sampling circuit, and the other end is connected to the standard reference voltage of the reference voltage circuit to complete the real-time comparison between the two. When the output voltage of the adjustable power supply deviates due to input voltage fluctuations and load changes, a difference will be generated between the actual voltage signal and the reference voltage. The comparison and amplification circuit will linearly amplify this tiny deviation signal and convert it into a control signal that can drive the adjustment circuit to work, providing sufficient power support for subsequent voltage correction and ensuring that the deviation can be identified and amplified in a timely manner.
The adjustment circuit corrects the voltage to achieve regulated output
The adjustment circuit is the execution unit of the voltage stabilization work of the adjustable power supply. It receives the control signal transmitted by the comparison and amplification circuit, and corrects the voltage input to the output end in real time by changing its own on-state voltage drop. The core of the circuit is a power adjustment transistor. When the output voltage of the adjustable power supply is too high, the control signal will increase the on-state voltage drop of the adjustment transistor to reduce the output voltage; when the output voltage is too low, the on-state voltage drop of the adjustment transistor decreases to increase the output voltage. The whole process is completed in an instant, forming a continuous closed-loop regulation, so that the output voltage of the adjustable power supply is always stable at the value preset by the user, without being affected by changes in external working conditions.
The voltage regulation process of an adjustable power supply is a closed-loop feedback system with interconnected circuits. Four core circuits each perform their specific functions and work together to achieve real-time monitoring and dynamic correction of the output voltage. It is this rigorous regulation process that allows the adjustable power supply to maintain stable voltage output under complex operating conditions, meeting the dual requirements of voltage accuracy and stability in electronic research and development, equipment testing, and other scenarios, making it an indispensable power supply device in various electronic fields.
